PRODUCT FEATURES

Conductor Material：High-conductivity Copper & optional tin/silver plating

Conductor Thickness：1.0 mm to 3.0 mm per layer（customizable）

Insulation Type：PET, Polyimide or Epoxy Resin — multilayer

Insulation Thickness：0.2 mm to 0.5 mm per layer; dielectric strength ≥ 20 kV/mm

Rated Voltage：Up to 1000 V AC/DC (IEC 60664-1 compliant)

Rack/PDU modules: 100–600 A

UPS rectifier/inverter stacks: 400–1,600 A

Busway/backbone segments: 1,000–3,000+ A (with thicker stacks and enhanced cooling)
